| Фотографии | Производитель. Часть # | Доступность | Цены | Количество | Таблицы данных | Package/Case | Packaging | Series | ProductStatus | Resistance | Tolerance | Power(Watts) | Composition | Features | TemperatureCoefficient | OperatingTemperature | Size/Dimension | Height-Seated(Max) | NumberofTerminations |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
40J500ERES 500 OHM 5% 10W AXIAL |
5,143 | 1.81 |
RFQ |
Datasheet |
Axial | Bulk | Ohmicone® 40 | Active | 500 Ohms | ±5% | 10W | Wirewound | - | ±20ppm/°C | - | Axial | 0.406 Dia x 1.902 L (10.30mm x 48.30mm) | - |
|
25J82RERES 82 OHM 5% 5W AXIAL |
9,586 | 1.82 |
RFQ |
Datasheet |
Axial | Bulk | 20 | Active | 82 Ohms | ±5% | 5W | Wirewound | Flame Retardant Coating, Safety | ±30ppm/°C | - | Axial | 0.276 Dia x 1.016 L (7.00mm x 25.80mm) | - |
|
|
25J56RERES 56 OHM 5% 5W AXIAL |
7,502 | 1.82 |
RFQ |
Datasheet |
Axial | Bulk | 20 | Active | 56 Ohms | ±5% | 5W | Wirewound | Flame Retardant Coating, Safety | ±30ppm/°C | - | Axial | 0.276 Dia x 1.016 L (7.00mm x 25.80mm) | - |
|
45F1R5ERES 1.5 OHM 1% 5W AXIAL |
8,753 | 1.82 |
RFQ |
Datasheet |
Axial | Bulk | Ohmicone® 40 | Active | 1.5 Ohms | ±1% | 5W | Wirewound | - | ±50ppm/°C | - | Axial | 0.343 Dia x 0.937 L (8.70mm x 23.80mm) | - |
|
|
45F7R5ERES 7.5 OHM 1% 5W AXIAL |
6,259 | 1.82 |
RFQ |
Datasheet |
Axial | Bulk | Ohmicone® 40 | Active | 7.5 Ohms | ±1% | 5W | Wirewound | - | ±50ppm/°C | - | Axial | 0.343 Dia x 0.937 L (8.70mm x 23.80mm) | - |
|
22J200ERES 200 OHM 5% 2W AXIAL |
5,038 | 1.60 |
RFQ |
Datasheet |
Axial | Bulk | 20 | Active | 200 Ohms | ±5% | 2W | Wirewound | Flame Retardant Coating, Safety | ±30ppm/°C | - | Axial | 0.220 Dia x 0.421 L (5.60mm x 10.70mm) | - |
|
|
22J390ERES 390 OHM 5% 2W AXIAL |
6,414 | 1.60 |
RFQ |
Datasheet |
Axial | Bulk | 20 | Active | 390 Ohms | ±5% | 2W | Wirewound | Flame Retardant Coating, Safety | ±30ppm/°C | - | Axial | 0.220 Dia x 0.421 L (5.60mm x 10.70mm) | - |
|
|
SM104031115FERES 11.1M OHM 1% 1.5W RADIAL |
6,957 | 1.62 |
RFQ |
Datasheet |
Radial | Bulk | Slim-Mox | Active | 11.1 MOhms | ±1% | 1.5W | Thick Film | High Voltage, Non-Inductive | 50ppm/°C | -55°C ~ 110°C | Radial | 1.080 L x 0.100 W (27.43mm x 2.54mm) | 0.340 (8.64mm) |
|
|
TUW15J330ERES 330 OHM 5% 15W AXIAL |
5,543 | 1.65 |
RFQ |
Datasheet |
Axial | Bulk | TUW | Active | 330 Ohms | ±5% | 15W | Wirewound | Flame Proof, Safety | ±350ppm/°C | - | Axial | 0.492 x 0.453 Rectangular x 1.929 L (12.50mm x 11.50mm x 49.00mm) | - |
|
|
45J4K7ERES 4.7K OHM 5% 5W AXIAL |
6,843 | 1.65 |
RFQ |
Datasheet |
Axial | Bulk | Ohmicone® 40 | Active | 4.7 kOhms | ±5% | 5W | Wirewound | - | ±20ppm/°C | - | Axial | 0.343 Dia x 0.937 L (8.70mm x 23.80mm) | - |
|
|
45J3K3ERES 3.3K OHM 5% 5W AXIAL |
7,585 | 1.65 |
RFQ |
Datasheet |
Axial | Bulk | Ohmicone® 40 | Active | 3.3 kOhms | ±5% | 5W | Wirewound | - | ±20ppm/°C | - | Axial | 0.343 Dia x 0.937 L (8.70mm x 23.80mm) | - |
|
|
45J4K5ERES 4.5K OHM 5% 5W AXIAL |
7,399 | 1.65 |
RFQ |
Datasheet |
Axial | Bulk | Ohmicone® 40 | Active | 4.5 kOhms | ±5% | 5W | Wirewound | - | ±20ppm/°C | - | Axial | 0.343 Dia x 0.937 L (8.70mm x 23.80mm) | - |
|
|
45J6K0ERES 6K OHM 5% 5W AXIAL |
9,241 | 1.65 |
RFQ |
Datasheet |
Axial | Bulk | Ohmicone® 40 | Active | 6 kOhms | ±5% | 5W | Wirewound | - | ±20ppm/°C | - | Axial | 0.343 Dia x 0.937 L (8.70mm x 23.80mm) | - |
|
|
SM101031006FRES 100M OHM 1% 1/2W RADIAL |
9,006 | 1.66 |
RFQ |
Datasheet |
Radial | Bulk | Slim-Mox | Active | 100 MOhms | ±1% | 0.5W, 1/2W | Thick Film | High Voltage, Non-Inductive | 50ppm/°C | -55°C ~ 110°C | Radial | 0.330 L x 0.100 W (8.38mm x 2.54mm) | 0.340 (8.64mm) |
|
|
B12J8K5ERES 8.5K OHM 5% 12W AXIAL |
7,311 | 1.66 |
RFQ |
Datasheet |
Axial | Bulk | B12 | Active | 8.5 kOhms | ±5% | 12W | Wirewound | Flame Retardant Coating, Safety | ±260ppm/°C | - | Axial | 0.313 Dia x 1.750 L (7.94mm x 44.45mm) | - |
|
|
85F110RES 110 OHM 1% 5W AXIAL |
9,534 | 1.67 |
RFQ |
Datasheet |
Axial | Bulk | Acrasil® 80 | Active | 110 Ohms | ±1% | 5W | Wirewound | - | ±20ppm/°C | - | Axial | 0.343 Dia x 0.937 L (8.70mm x 23.80mm) | - |
|
|
SM102032505FERES 25M OHM 1% 1W RADIAL |
5,739 | 1.67 |
RFQ |
Datasheet |
Radial | Bulk | Slim-Mox | Active | 25 MOhms | ±1% | 1W | Thick Film | High Voltage, Non-Inductive | 50ppm/°C | -55°C ~ 110°C | Radial | 0.580 L x 0.100 W (14.73mm x 2.54mm) | 0.340 (8.64mm) |
|
|
SM103036654FERES 6.65M OHM 1% 1.25W RADIAL |
5,091 | 1.68 |
RFQ |
Datasheet |
Radial | Bulk | Slim-Mox | Active | 6.65 MOhms | ±1% | 1.25W | Thick Film | High Voltage, Non-Inductive | 50ppm/°C | -55°C ~ 110°C | Radial | 0.830 L x 0.100 W (21.08mm x 2.54mm) | 0.340 (8.64mm) |
|
|
SM103039884FERES 9.88M OHM 1% 1.25W RADIAL |
8,241 | 1.68 |
RFQ |
Datasheet |
Radial | Bulk | Slim-Mox | Active | 9.88 MOhms | ±1% | 1.25W | Thick Film | High Voltage, Non-Inductive | 50ppm/°C | -55°C ~ 110°C | Radial | 0.830 L x 0.100 W (21.08mm x 2.54mm) | 0.340 (8.64mm) |
|
|
22J75RERES 75 OHM 5% 2W AXIAL |
5,934 | 1.70 |
RFQ |
Datasheet |
Axial | Bulk | 20 | Active | 75 Ohms | ±5% | 2W | Wirewound | Flame Retardant Coating, Safety | ±30ppm/°C | - | Axial | 0.220 Dia x 0.421 L (5.60mm x 10.70mm) | - |
