| Фотографии | Производитель. Часть # | Доступность | Цены | Количество | Таблицы данных | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLP385(D4YH-TL,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
12,756 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 75% @ 5mA | 150% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(D4YH-TR,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
11,718 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 75% @ 5mA | 150% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(D4Y-TPL,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
10,324 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 50% @ 5mA | 150% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(D4Y-TPR,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
11,465 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 50% @ 5mA | 150% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(GRH-TPL,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
11,356 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 150% @ 5mA | 300% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(GRH-TPR,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
12,385 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 150% @ 5mA | 300% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(GRL-TPL,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
12,856 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 100% @ 5mA | 200% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(GRL-TPR,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
12,124 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 100% @ 5mA | 200% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(GR-TPL,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
12,054 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 100% @ 5mA | 300% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(GR-TPR,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
13,898 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 100% @ 5mA | 300% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(TPL,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
13,330 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 50% @ 5mA | 600% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(TPR,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
14,955 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 50% @ 5mA | 600% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
VO618A-3X018TOPTOCOUPLER, PHOTOTRANSISTOR OUT |
14,785 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5300Vrms | 100% @ 1mA | 200% @ 1mA | 4.2µs, 23µs | 3µs, 14µs | DC | Transistor | 80V | 50mA | 1.1V | 60 mA | 400mV | -55°C ~ 110°C | Surface Mount |
|
VO618A-2X009TOPTOCOUPLER, PHOTOTRANSISTOR OUT |
14,059 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5300Vrms | 63% @ 1mA | 125% @ 1mA | 4.2µs, 23µs | 3µs, 14µs | DC | Transistor | 80V | 50mA | 1.1V | 60 mA | 400mV | -55°C ~ 110°C | Surface Mount |
|
VO618A-2X017TOPTOCOUPLER, PHOTOTRANSISTOR OUT |
10,944 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5300Vrms | 63% @ 1mA | 125% @ 1mA | 4.2µs, 23µs | 3µs, 14µs | DC | Transistor | 80V | 50mA | 1.1V | 60 mA | 400mV | -55°C ~ 110°C | Surface Mount |
|
|
TLP385(GB-TPR,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
12,542 | 0.55 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 5000Vrms | 100% @ 5mA | 600% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
PS2561A-1-V-AOPTOISOLATOR 5KV TRANS 4DIP |
14,879 | 0.17 |
RFQ |
Datasheet |
Tube | NEPOC | Not For New Designs | 1 | 5000Vrms | 50% @ 5mA | 400% @ 5mA | - | 3µs, 5µs | DC | Transistor | 70V | 30mA | 1.2V | 30 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
PS2561AL1-1-AOPTOISOLATOR 5KV TRANS 4DIP |
11,768 | 0.17 |
RFQ |
Datasheet |
Tube | NEPOC | Not For New Designs | 1 | 5000Vrms | 50% @ 5mA | 400% @ 5mA | - | 3µs, 5µs | DC | Transistor | 70V | 30mA | 1.2V | 30 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
TLP185(GB,E)OPTOISO 3.75KV TRANS 6-SO 4 LEAD |
2,992 | 0.17 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 3750Vrms | 100% @ 5mA | 400% @ 5mA | 9µs, 9µs | 5µs, 9µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
-VG.JPG)
|
EL851(S1)(TU)OPTOISO 5KV TRANSISTOR 4-SMD |
14,204 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 1 | 5000Vrms | 50% @ 5mA | 600% @ 5mA | - | 4µs, 5µs | DC | Transistor | 350V | 50mA | 1.2V | 60 mA | 400mV | -55°C ~ 100°C | Surface Mount |
