| Фотографии | Производитель. Часть # | Доступность | Цены | Количество | Таблицы данных | Packaging | Series | ProductStatus | NumberofChannels | Inputs-Side1/Side2 | Voltage-Isolation | CommonModeTransientImmunity(Min) | InputType | OutputType | Current-Output/Channel | DataRate | PropagationDelaytpLH/tpHL(Max) | Rise/FallTime(Typ) | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | Voltage-Supply | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PS9351L-V-AXSDIP |
8,495 | 8.72 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 5000Vrms | 15kV/µs | DC | Open Collector | 2 mA | 15Mbps | 60ns, 60ns | 4ns, 4ns | 1.56V | 25mA | 4.5V ~ 5.5V | -40°C ~ 100°C | Surface Mount | |
|
|
PS9351L2-V-AXSDIP |
6,396 | 8.78 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 5000Vrms | 15kV/µs | DC | Open Collector | 2 mA | 15Mbps | 60ns, 60ns | 4ns, 4ns | 1.56V | 25mA | 4.5V ~ 5.5V | -40°C ~ 100°C | Surface Mount |
|
|
PS9324L-V-AXSDIP |
6,494 | 7.52 |
RFQ |
Datasheet |
Cut Tape (CT),Strip | - | Active | 1 | 1/0 | 5000Vrms | 15kV/µs | DC | Open Collector | 25 mA | 10Mbps | 75ns, 75ns | 20ns, 5ns | 1.55V | 25mA | 2.7V ~ 5.5V | -40°C ~ 110°C | Surface Mount |
|
PS9822-1-AXSO-8 |
8,282 | 7.53 |
RFQ |
Datasheet |
Strip | NEPOC | Active | 1 | 1/0 | 2500Vrms | 15kV/µs | DC | Open Collector | 20 mA | 1Mbps | 700ns, 500ns | 60ns, 70ns | 1.6V | 20mA | 7V | -40°C ~ 100°C | Surface Mount |
|
PS9303L-AXOPTOISO 5KV PUSH PULL 6DIP GW |
6,928 | 7.72 |
RFQ |
Datasheet |
Bulk | NEPOC | Not For New Designs | 1 | 1/0 | 5000Vrms | 15kV/µs | DC | Push-Pull, Totem Pole | 25 mA | 1Mbps | 500ns, 550ns | 120ns, 90ns | 1.6V | 20mA | 4.5V ~ 20V | -40°C ~ 100°C | Surface Mount |
|
|
PS9822-1-V-AXSO-8 |
9,794 | 7.80 |
RFQ |
Datasheet |
Strip | NEPOC | Active | 1 | 1/0 | 2500Vrms | 15kV/µs | DC | Open Collector | 20 mA | 1Mbps | 700ns, 500ns | 60ns, 70ns | 1.6V | 20mA | 7V | -40°C ~ 100°C | Surface Mount |
|
|
PS9822-2-V-AXSO-8 |
3,249 | 10.86 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | NEPOC | Active | 2 | 1/0 | 2500Vrms | 15kV/µs | DC | Open Collector | 20 mA | 1Mbps | 700ns, 500ns | 60ns, 70ns | 1.6V | 15mA | 7V | -40°C ~ 100°C | Surface Mount |
|
|
PS9309L-V-AXSDIP |
8,189 | 7.92 |
RFQ |
Datasheet |
Strip | - | Active | 1 | 1/0 | 5000Vrms | 15kV/µs | DC | Push-Pull, Totem Pole | 25 mA | - | 200ns, 200ns | 24ns, 3.2ns | 1.55V | 20mA | 4.5V ~ 20V | -40°C ~ 110°C | Surface Mount |
|
PS9817A-1-AXOPTOISO 2.5KV OPEN COLL 8SSOP |
6,561 | 8.36 |
RFQ |
Datasheet |
Bulk | NEPOC | Not For New Designs | 1 | 1/0 | 2500Vrms | 15kV/µs | DC | Open Collector | 25 mA | 10Mbps | 75ns, 75ns | 20ns, 5ns | 1.65V | 20mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
|
PS9821-1-V-AXSO-8 |
8,238 | 8.47 |
RFQ |
Datasheet |
Strip | NEPOC | Active | 1 | 1/0 | 2500Vrms | 15kV/µs | DC | Open Collector | 25 mA | 15Mbps | 75ns, 75ns | 20ns, 5ns | 1.65V | 20mA | 2.7V ~ 3.6V | -40°C ~ 85°C | Surface Mount |
|
|
PS9851-1-V-AXSO-8 |
6,511 | 9.61 |
RFQ |
Datasheet |
Strip | - | Active | 1 | 1/0 | 2500Vrms | 10kV/µs | DC | Push-Pull, Totem Pole | 2 mA | 15Mbps | 60ns, 60ns | 4ns, 4ns | 1.6V | 20mA | 4.5V ~ 5.5V | -40°C ~ 100°C | Surface Mount |
|
|
PS9817A-2-V-AXSO-8 |
7,838 | 9.72 |
RFQ |
Datasheet |
Strip | NEPOC | Active | 1 | 1/0 | 2500Vrms | 15kV/µs | DC | Open Collector | 25 mA | 10Mbps | 75ns, 75ns | 20ns, 5ns | 1.65V | 15mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
|
OLS500HIGH CMR, HIGH-SPEED LOGIC GATE |
4,916 | 62.94 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 1/1 | 1500VDC | 1kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 10Mbps | 60ns, 60ns | - | 1.8V | 40mA | 7V | -55°C ~ 125°C | Surface Mount |
|
HCPL-5230OPTOISO 1.5KV 2CH PUSH PULL 8DIP |
988 | 129.25 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 1500VDC | 1kV/µs | DC | Push-Pull, Totem Pole | 15 mA | 5MBd | 350ns, 350ns | 45ns, 10ns | 1.3V | 8mA | 4.5V ~ 20V | -55°C ~ 125°C | Through Hole |
|
6N137SMT/ROPTOISO 5KV 1CH OPEN COLL 8SMD |
9,660 | 1.06 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 5000Vrms | 5kV/µs | DC | Open Collector | 50 mA | 10Mbps | 75ns, 75ns | 40ns, 10ns | 1.4V | 50mA | 7V | -55°C ~ 85°C | Surface Mount |
|
H11L3SR2MOPTOISO 4.17KV OPN COLL 6SMD |
9,784 | 1.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 4170Vrms | - | DC | Open Collector | 50 mA | 1MHz | 4µs, 4µs | 100ns, 100ns | 1.2V | 30mA | 3V ~ 15V | -40°C ~ 85°C | Surface Mount |
|
|
6N137A-X007TOPTOISO 5KV 1CH OPEN COLL 8SMD |
9,943 | 1.59 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 5000Vrms | 1kV/µs | DC | Open Collector | 50 mA | 10MBd | 75ns, 75ns | 27ns, 10ns | 1.35V | 20mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
TLP2710(TP,EOPTOCOUPLER HI SPEED LOGIC OUTPU |
5,363 | 1.60 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 5000Vrms | 25kV/µs | DC | Push-Pull, Totem Pole | 10 mA | 5MBd | 250ns, 250ns | 11ns, 13ns | 1.9V (Max) | 8mA | 2.7V ~ 5.5V | -40°C ~ 125°C | Surface Mount |
|
|
TLP2719(TP4,EOPTOCOUPLER HI SPEED LOGIC OUTPU |
6,988 | 1.75 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 5000Vrms | 10kV/µs | DC | Open Collector | 8 mA | 1MBd | 800ns, 800ns | - | 1.6V | 25mA | 4.5V ~ 20V | -40°C ~ 100°C | Surface Mount |
|
|
ICPLW137SMT&ROPTOCOUPLER |
8,851 | 1.78 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 5000Vrms | 10kV/µs | DC | Open Collector, Schottky Clamped | 50 mA | 10Mbps | 100ns, 100ns | 23ns, 10ns | 1.38V | 20mA | 7V | -40°C ~ 105°C | Surface Mount |
