Производитель. Часть #	Доступность	Цены	Количество	Таблицы данных	Packaging	Series	ProductStatus	LogicType	NumberofCircuits	NumberofInputs	Features	Voltage-Supply	Current-Quiescent(Max)	Current-OutputHighLow	LogicLevel-Low	LogicLevel-High	MaxPropagationDelay@VMaxCL	OperatingTemperature	MountingType
N74F38D-Q100118 NAND GATE, F/FAST SERIES, TTL NXP USA Inc.	12,640	0.18	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
CD74HC32EX128 IC GATE OR 4CH 2-INP 14DIP Harris Corporation	11,851	0.18	- + RFQ		Bulk	74HC	Active	OR Gate	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	15ns @ 6V, 50pF	-55°C ~ 125°C	Through Hole
74LVC3G14GF IC INVERT SCHMITT 3CH 3-IN 8XSON Nexperia USA Inc.	11,336	0.19	- + RFQ	Datasheet	Bulk	74LVC	Active	Inverter	3	3	Schmitt Trigger	1.65V ~ 5.5V	4 µA	32mA, 32mA	1.1V ~ 2.5V	1.7V ~ 3.8V	4.7ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
74LVQ14SJ IC INVERT SCHMITT 6CH 1-IN 14SOP Fairchild Semiconductor	9,860	0.19	- + RFQ	Datasheet	Tube	74LVQ	Obsolete	Inverter	6	1	Schmitt Trigger	2V ~ 3.6V	2 µA	12mA, 12mA	0.5V	2.2V	13.5ns @ 3.3V, 50pF	-40°C ~ 85°C	Surface Mount
74HC1G32CME-E IC GATE OR 1CH 2-INP CMPAK-6 Renesas Electronics America Inc	11,125	0.19	- + RFQ		Bulk	74HC	Active	OR Gate	1	2	-	2V ~ 6V	20 µA	2.6mA, 2.6mA	0.5V ~ 1.8V	1.5V ~ 4.2V	23ns @ 6V, 50pF	-40°C ~ 125°C	Surface Mount
74HC1G00CME-E IC GATE NAND 1CH 2-INP CMPAK-6 Renesas Electronics America Inc	11,620	0.19	- + RFQ		Bulk	74HC	Active	NAND Gate	1	2	-	2V ~ 6V	20 µA	2.6mA, 2.6mA	0.5V ~ 1.8V	1.5V ~ 4.2V	23ns @ 6V, 50pF	-40°C ~ 125°C	Surface Mount
MC74HCT14AFL1 IC GATE XNOR 4CH 2-INP SOEIAJ Motorola	14,726	0.19	- + RFQ		Bulk	74HCT	Active	XNOR (Exclusive NOR)	4	2	Schmitt Trigger	4.5V ~ 5.5V	1 µA	4mA, 4mA	0.5V ~ 0.6V	1.9V ~ 2.1V	32ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
MC74HC32AFL2 IC GATE OR 4CH 2-INP SOEIAJ-14 Motorola	13,768	0.19	- + RFQ		Bulk	74HC	Active	OR Gate	4	2	-	2V ~ 6V	1 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	13ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
MC74HC86AFL2 IC GATE XNOR 4CH 2-INP SOEIAJ-14 Motorola	14,663	0.19	- + RFQ		Bulk	74HC	Active	XNOR (Exclusive NOR)	4	2	-	2V ~ 6V	1 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	17ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
CD4072BNS IC GATE OR 2CH 4-INP 14-SO Texas Instruments	12,010	0.19	- + RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
NLV14001BDR2 IC GATE NOR 4CH 2-INP 14-SOIC onsemi	11,064	0.19	- + RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
SN74ALS15ADR AND GATE, ALS SERIES Texas Instruments	14,289	0.19	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74LVC132AD-Q100118 NAND GATE, LVC/LCX/Z SERIES NXP USA Inc.	7,495	0.19	- + RFQ	Datasheet	Bulk	*	Obsolete	-	-	-	-	-	-	-	-	-	-	-	-
DM7401N NAND GATE, TTL, PDIP14 National Semiconductor	13,256	0.19	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74LV132DB,118 NAND GATE, LV/LV-A/LVX/H SERIES NXP USA Inc.	976	6000.00	- + RFQ	Datasheet	Bulk	74LV	Active	NAND Gate	4	2	Schmitt Trigger	1V ~ 5.5V	40 µA	12mA, 12mA	0.3V ~ 1.2V	1.4V ~ 3.9V	9ns @ 5V, 50pF	-40°C ~ 125°C
SN74LS133ML1 13-I NAND onsemi	13,411	0.19	- + RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74ACT00SJ IC GATE NAND 4CH 2-INP 14SOP Fairchild Semiconductor	5,206	0.19	- + RFQ	Datasheet	Tube	74ACT	Obsolete	NAND Gate	4	2	-	4.5V ~ 5.5V	2 µA	24mA, 24mA	0.8V	2V	9ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
MC74HC7266AFR1 IC GATE XNOR 4CH 2-INP SOEIAJ-14 onsemi	12,289	0.19	- + RFQ		Bulk	74HC	Active	XNOR (Exclusive NOR)	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.3V ~ 1.2V	1.5V ~ 4.2V	20ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
74LVX14SJX IC INVERT SCHMITT 6CH 1-IN 14SOP Fairchild Semiconductor	4,903	0.19	- + RFQ	Datasheet	Bulk	74LVX	Obsolete	Inverter	6	1	Schmitt Trigger	2V ~ 3.6V	2 µA	4mA, 4mA	0.9V	2.2V	14.1ns @ 3.3V, 50pF	-40°C ~ 85°C	Surface Mount
CD4073BNS IC GATE AND 3CH 3-INP 14-SO Texas Instruments	11,213	0.19	- + RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
