| Фотографии | Производитель. Часть # | Доступность | Цены | Количество | Таблицы данных | Package/Case | Packaging | Series | ProductStatus | Resistance | Tolerance | Power(Watts) | Composition | Features | TemperatureCoefficient | OperatingTemperature | Ratings | Size/Dimension | Height-Seated(Max) | NumberofTerminations |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PWR163S-25-2R20JERES SMD 2.2 OHM 5% 25W DPAK |
9,681 | 3.61 |
RFQ |
Datasheet |
TO-252-3, DPak (2 Leads + Tab), SC-63 | Tape & Reel (TR),Cut Tape (CT) | PWR163 | Active | 2.2 Ohms | ±5% | 25W | Thick Film | Automotive AEC-Q200, Current Sense, Pulse Withstanding | ±100ppm/°C | -55°C ~ 155°C | AEC-Q200 | 0.320 L x 0.324 W (8.13mm x 8.22mm) | 0.125 (3.17mm) | |
|
MIF1000AFKMGNHWSMICROWAVE RESISTOR 2016 100 OHM |
8,212 | 3.25 |
RFQ |
Datasheet |
Nonstandard | Tray | MIF | Active | 100 Ohms | ±1% | 0.05W, 1/20W | Thin Film | Bonding Mountable, Moisture Resistant, RF, High Frequency | ±100ppm/°C | -55°C ~ 125°C | - | 0.020 L x 0.016 W (0.50mm x 0.40mm) | 0.011 (0.28mm) | |
|
|
MIF5000BFKMGNHWSMICROWAVE RESISTOR 2016 50 OHM 1 |
7,021 | 3.25 |
RFQ |
Datasheet |
Nonstandard | Tray | MIF | Active | 50 Ohms | ±1% | 0.05W, 1/20W | Thin Film | Bonding Mountable, Moisture Resistant, RF, High Frequency | ±100ppm/°C | -55°C ~ 125°C | - | 0.020 L x 0.016 W (0.50mm x 0.40mm) | 0.011 (0.28mm) | |
|
|
PWR163S-25-R100JERES 0.1 OHM 5% 25W DPAK |
5,467 | 3.68 |
RFQ |
Datasheet |
TO-252-3, DPak (2 Leads + Tab), SC-63 | Tape & Reel (TR),Cut Tape (CT) | PWR163 | Active | 100 mOhms | ±5% | 25W | Thick Film | Automotive AEC-Q200, Current Sense, Pulse Withstanding | ±100ppm/°C | -55°C ~ 155°C | AEC-Q200 | 0.320 L x 0.324 W (8.13mm x 8.22mm) | 0.125 (3.17mm) | |
|
|
PWR163S-25-R400FERES 0.4 OHM 1% 25W DPAK |
6,271 | 3.81 |
RFQ |
Datasheet |
TO-252-3, DPak (2 Leads + Tab), SC-63 | Tape & Reel (TR),Cut Tape (CT) | PWR163 | Active | 400 mOhms | ±1% | 25W | Thick Film | Automotive AEC-Q200, Current Sense, Pulse Withstanding | ±100ppm/°C | -55°C ~ 155°C | AEC-Q200 | 0.320 L x 0.324 W (8.13mm x 8.22mm) | 0.125 (3.17mm) | |
|
ALX25W150RBET2512 ALNI CHIP 0.1% |
9,957 | 4.16 |
RFQ |
- | Tape & Reel (TR),Cut Tape (CT) | - | Active | - | - | - | - | - | - | - | - | - | - | ||
|
|
ALX25W100RBET2512 ALNI CHIP 0.1% |
5,973 | 4.16 |
RFQ |
- | Tape & Reel (TR),Cut Tape (CT) | - | Active | - | - | - | - | - | - | - | - | - | - | ||
|
|
ALX25W1K00BET2512 ALNI CHIP 0.1% |
9,994 | 4.16 |
RFQ |
- | Tape & Reel (TR),Cut Tape (CT) | - | Active | - | - | - | - | - | - | - | - | - | - | ||
|
|
ALX25W10K0BET2512 ALNI CHIP 0.1% |
7,053 | 4.16 |
RFQ |
- | Tape & Reel (TR),Cut Tape (CT) | - | Active | - | - | - | - | - | - | - | - | - | - | ||
|
|
ALX25W4K99BET2512 ALNI CHIP 0.1% |
5,283 | 4.16 |
RFQ |
- | Tape & Reel (TR),Cut Tape (CT) | - | Active | - | - | - | - | - | - | - | - | - | - | ||
|
|
ALX25W75R0BET2512 ALNI CHIP 0.1% |
5,258 | 4.16 |
RFQ |
- | Tape & Reel (TR),Cut Tape (CT) | - | Active | - | - | - | - | - | - | - | - | - | - | ||
|
MSP2B2R200JR10E3SFERNICE FIXED RESISTORS |
5,439 | 6.40 |
RFQ |
4527 J-Lead | Tape & Reel (TR),Cut Tape (CT) | MSP | Active | 2.2 Ohms | ±5% | 2W | Wirewound | - | ±50ppm/°C | -55°C ~ 275°C | - | 0.449 L x 0.276 W (11.40mm x 7.00mm) | 0.205 (5.20mm) | ||
|
HVC2512T5004JETRES SMD 5M OHM 5% 1W 2512 |
6,421 | 4.16 |
RFQ |
Datasheet |
2512 (6432 Metric) | Tape & Reel (TR),Cut Tape (CT) | HVC | Active | 5 MOhms | ±5% | 1W | Thick Film | High Voltage | ±100ppm/°C | -55°C ~ 155°C | - | 0.248 L x 0.138 W (6.30mm x 3.50mm) | 0.022 (0.55mm) | |
|
|
PWR163S-25-4700FRES 470 OHM 1% 25W D2PAK |
5,787 | 3.76 |
RFQ |
Datasheet |
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | Tube | PWR163 | Active | 470 Ohms | ±1% | 25W | Thick Film | Automotive AEC-Q200, Current Sense, Pulse Withstanding | ±100ppm/°C | -55°C ~ 155°C | AEC-Q200 | 0.320 L x 0.324 W (8.13mm x 8.22mm) | 0.125 (3.17mm) | |
|
HVC4020V2506JETRES 250M OHM 5% 1.5W 4020 |
9,676 | 2.75 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | HVC | Active | 250 MOhms | ±5% | 1.5W | Thick Film | High Voltage | ±50ppm/°C | -55°C ~ 155°C | - | 0.402 L x 0.201 W (10.20mm x 5.10mm) | 0.031 (0.80mm) | |
|
MIC1000AFLMGNHT5MICROWAVE RESISTOR, 0402, 100 OH |
6,020 | 5.41 |
RFQ |
Datasheet |
0402 (1005 Metric) | Tape & Reel (TR),Cut Tape (CT) | MIC | Active | 100 Ohms | ±1% | 0.125W, 1/8W | Thin Film | Bonding Mountable, Moisture Resistant, RF, High Frequency | ±200ppm/°C | -55°C ~ 125°C | - | 0.039 L x 0.020 W (1.00mm x 0.50mm) | 0.012 (0.30mm) | |
|
PWR263S-35-7500FRES SMD 750 OHM 1% 35W D2PAK |
6,069 | 2.88 |
RFQ |
Datasheet |
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | Tube | PWR263S-35 | Active | 750 Ohms | ±1% | 35W | Thick Film | Automotive AEC-Q200, Current Sense, Pulse Withstanding | ±100ppm/°C | -55°C ~ 155°C | AEC-Q200 | 0.398 L x 0.409 W (10.10mm x 10.40mm) | 0.177 (4.50mm) | |
|
|
PWR263S-35-3000FRES SMD 300 OHM 1% 35W D2PAK |
7,288 | 2.88 |
RFQ |
Datasheet |
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | Tube | PWR263S-35 | Active | 300 Ohms | ±1% | 35W | Thick Film | Automotive AEC-Q200, Current Sense, Pulse Withstanding | ±100ppm/°C | -55°C ~ 155°C | AEC-Q200 | 0.398 L x 0.409 W (10.10mm x 10.40mm) | 0.177 (4.50mm) | |
|
CH0402-150RGFPTRES CH 0402 THIN FILM |
8,231 | 7.34 |
RFQ |
Datasheet |
0402 (1005 Metric) | Tape & Reel (TR),Cut Tape (CT) | CH | Active | 150 Ohms | ±2% | 0.05W, 1/20W | Thin Film | RF, High Frequency | ±100ppm/°C | -55°C ~ 155°C | - | 0.039 L x 0.024 W (1.00mm x 0.60mm) | 0.025 (0.63mm) | |
|
|
CH0402-75RGFPTRES CH 0402 THIN FILM |
9,293 | 7.34 |
RFQ |
Datasheet |
0402 (1005 Metric) | Tape & Reel (TR),Cut Tape (CT) | CH | Active | 75 Ohms | ±2% | 0.05W, 1/20W | Thin Film | RF, High Frequency | ±100ppm/°C | -55°C ~ 155°C | - | 0.039 L x 0.024 W (1.00mm x 0.60mm) | 0.025 (0.63mm) |
