| Фотографии | Производитель. Часть # | Доступность | Цены | Количество | Таблицы данных | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
UPM0J102MHD6TOCAP ALUM 1000UF 20% 6.3V RADIAL |
14,957 | 0.97 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UPM | Not For New Designs | 1000 µF | ±20% | 6.3 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 770 mA @ 120 Hz | 890 mA @ 10 kHz | 85 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 0.669 (17.00mm) | - | Through Hole |
|
865060153008CAP ALUM 470UF 20% 6.3V SMD |
14,589 | 0.71 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | WCAP-ASLL | Active | 470 µF | ±20% | 6.3 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 325 mA @ 120 Hz | 500 mA @ 100 kHz | 170 mOhms | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
ESMG251ELL330MK20SCAP ALUM 33UF 20% 250V RADIAL |
9,899 | 2.04 |
RFQ |
Datasheet |
Bulk | SMG | Active | 33 µF | ±20% | 250 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 230 mA @ 120 Hz | 414 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 0.846 (21.50mm) | - | Through Hole |
|
UPZ2D181MHDCAP ALUM 180UF 20% 200V RADIAL |
6,121 | 2.04 |
RFQ |
Datasheet |
Bulk | UPZ | Active | 180 µF | ±20% | 200 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | - | - | General Purpose | 700 mA @ 120 Hz | 980 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.476 (37.50mm) | - | Through Hole |
|
860160475024CAP ALUM 560UF 20% 25V RADIAL |
13,073 | 0.72 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATLL | Active | 560 µF | ±20% | 25 V | - | 7000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 730.8 mA @ 120 Hz | 1.26 A @ 100 kHz | 150 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.689 (17.50mm) | - | Through Hole |
|
UPW1A392MHD6CAP ALUM 3900UF 20% 10V RADIAL |
5,909 | 2.05 |
RFQ |
Datasheet |
Bulk | UPW | Not For New Designs | 3900 µF | ±20% | 10 V | - | 8000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.879 A @ 120 Hz | 2.21 A @ 100 kHz | 29 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.787 (20.00mm) | - | Through Hole |
|
|
ESMG6R3ELL682MK25SCAP ALUM 6800UF 20% 6.3V RADIAL |
6,185 | 2.05 |
RFQ |
Datasheet |
Bulk | SMG | Active | 6800 µF | ±20% | 6.3 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.915 A @ 120 Hz | 2.0682 A @ 100 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.043 (26.50mm) | - | Through Hole |
|
EEV-TG1A472MCAP ALUM 4700UF 20% 10V SMD |
8,198 | 3.33 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TG | Active | 4700 µF | ±20% | 10 V | 75mOhm @ 100kHz | 2000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 845 mA @ 120 Hz | 1.3 A @ 100 kHz | - | - | 0.709 Dia (18.00mm) | 0.650 (16.50mm) | 0.748 L x 0.748 W (19.00mm x 19.00mm) | Surface Mount |
|
ELZA350ELL821MJ25SCAP ALUM 820UF 20% 35V RADIAL |
7,437 | 2.06 |
RFQ |
Datasheet |
Bulk | LZA | Active | 820 µF | ±20% | 35 V | - | 4000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.044 A @ 120 Hz | 1.74 A @ 100 kHz | 33 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 1.043 (26.50mm) | - | Through Hole |
|
EEE-FN2A270UPCAP ALUM 27UF 20% 100V SMD |
11,600 | 0.99 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 27 µF | ±20% | 100 V | 1.3Ohm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 84.5 mA @ 120 Hz | 130 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FN1V331UPCAP ALUM 330UF 20% 35V SMD |
13,781 | 0.99 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 330 µF | ±20% | 35 V | 160mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 390 mA @ 120 Hz | 600 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FN1H181UPCAP ALUM 180UF 20% 50V SMD |
14,106 | 0.99 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 180 µF | ±20% | 50 V | 340mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 227.5 mA @ 120 Hz | 350 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FN1E471UPCAP ALUM 470UF 20% 25V SMD |
14,186 | 0.99 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 470 µF | ±20% | 25 V | 160mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 390 mA @ 120 Hz | 600 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FN1V271UPCAP ALUM 270UF 20% 35V SMD |
13,613 | 0.99 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 270 µF | ±20% | 35 V | 160mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 390 mA @ 120 Hz | 600 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FN1A821UPCAP ALUM 820UF 20% 10V SMD |
10,510 | 0.99 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 820 µF | ±20% | 10 V | 160mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 420 mA @ 120 Hz | 600 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEE-HB1H330APCAP ALUM 33UF 20% 50V SMD |
7,588 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HB | Active | 33 µF | ±20% | 50 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 91 mA @ 120 Hz | 154.7 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
UHW1H821MHD6CAP ALUM 820UF 20% 50V RADIAL |
5,633 | 2.08 |
RFQ |
Datasheet |
Bulk | UHW | Not For New Designs | 820 µF | ±20% | 50 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.842 A @ 120 Hz | 3.07 A @ 100 kHz | 23 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
UBX2C680MHL1TNCAP ALUM 68UF 20% 160V RADIAL |
5,399 | 4.06 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | UBX | Active | 68 µF | ±20% | 160 V | - | 2000 Hrs @ 150°C | -40°C ~ 150°C | Polar | - | Automotive | 290 mA @ 120 Hz | 435 mA @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.846 (21.50mm) | - | Through Hole |
Series.jpg)
|
EEE-FK2A220LCAP ALUM 22UF 20% 100V SMD |
5,098 | 1.01 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FK, Halogen Free | Active | 22 µF | ±20% | 100 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 97.5 mA @ 120 Hz | 130 mA @ 100 kHz | 1.3 Ohms | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FK1K330LCAP ALUM 33UF 20% 80V SMD |
9,292 | 1.01 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FK, Halogen Free | Active | 33 µF | ±20% | 80 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 97.5 mA @ 120 Hz | 130 mA @ 100 kHz | 1.3 Ohms | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
